14-gauge formed aluminum sheet metal construction. Heat sink is made of aluminum extrusion. The driver can be serviced without removing the light engine or mixing chamber.

Fixture Body Finish

Metallic cool charcoal fi nish is standard, with custom colors available.


A removable 12-ft (3.7-m) power cord with a NEMA 5-15P plug is standard. Other plug types are available as options. The fi xture is protected by an externally removable fuse with onboard spare. Power draw is 115 watts.


All LED Drivers are high-frequency electronic, with a power factor >.94, THD <10%, and a Class A sound rating. LED Drivers are mounted internally to the fi xture housing. The power and control inputs are on the handle. The dimming protocol is DMX or DALI.

LED Technology

The fixture emits high quality illumination (>97 CRI) for broadcast and videoconferencing applications and offers variable white color from 3200 degrees Kelvin to 5600 degrees Kelvin.


Fixture has a 10-gauge horizontal extruded aluminum yoke, with palm handles standard. Each fi xture is supplied with a 2-inch OD C-clamp with an integral safety cable.


A variety of accessories are available.

Fixture Dimensions and Weight

13.50-in (342.90-mm) wide x 12.49-in (317.16-mm) high x 10.37-in (263.41-mm) deep. Overall width of the fi xture increases to 16.74-in (425.07-mm), with the palm handles included. Fixture Weight: 12.58-lb (5.71-kg)

See shipping information chart for gross weights and dimensions.
